MODEL: MIG-S2

Features:

1. Adopt Advanced IGBT inverter and PWM technology.

2. MIG/MMA/Lift-TIG 3 IN 1 machine. Built-in arc force and hot start.

3. Internal wire feeder, gear driven, support MAX 5kgs wire feeding.

4. Burn-back function is adjustable, easy to remove tip ball.

5. With GAS(solid) and GASLESS (flux) wire function.

6. 3PC structure is available, high duty cycle and easy to repair.

Specification:

Welding function:MIG/MMA/Lift-TIG

Input Voltage:  AC220V±15％

Frequency: 50/60Hz

Input Capacity: 5.2KVA

No-load Voltage: 64V

Current Range:  40-200A

Rated Duty Cycle:  60%

Welding Wire: 0.6/0.8/1.0mm

Insulation Class:  F

Protection Degree:  IP23

Packing Size: 520×300×370mm

Gross Weight: 12KGS
